Lever-type dial gauge ALPA CB060

Lever-type dial gauge ALPA CB060

Category: SKU: CB060
Characteristics
  • Dial test indicator, jeweled movement. Automatic inversion, according to DIN 2270A.
    Dovetail snug ø 6 mm. Carbide contact point.
Request information
Properties

  • Range: 0 ÷ 0,8 (CB0600,8ST) 0 ÷ 0,8 (CB0600,8L) 0 ÷ 0,28 (CB0600,28)
  • Resolution: 0,01 (CB0600,8ST) 0,01 (CB0600,8L) 0,002 (CB0600,28)
  • Measuring force: 0 ÷ 0,2
  • Weight: 170

Drawings
Variations
Code
Campo mm
Resolution mm
A mm
D mm
CB0600,28
Campo mm
0,28
Resolution mm
0,002
A mm
18
D mm
38,4
CB0600,8L
Campo mm
0,8
Resolution mm
0,01
A mm
40,6
D mm
3,5
CB0600,8ST
Campo mm
0,8
Resolution mm
38
A mm
21
D mm
3,5
