Centesimal dial gauge ALPA CB010

Centesimal dial gauge ALPA CB010

Category: SKU: CB010
Characteristics
  • Accuracy according to UNI 4180.
    Shockproof mechanism. Cylindrical mounting Ø 8 mm.
Request information
Properties

  • Range: 0 ÷ 10
  • Resolution: 0,01
  • Measuring force: 1,2 (CB01010ST) 1,5 (CB01010WP)
  • Weight: 145 (CB01010ST) 165 (CB01010WP)

Drawings
Variations
Code
Range mm
Resolution mm
A mm
B mm
C mm
E mm
F mm
CB01010ST
Range mm
0 ÷ 10
Resolution mm
0,01
A mm
48
B mm
65
C mm
56
E mm
18
F mm
15,8
CB01010STF
Range mm
0 ÷ 10
Resolution mm
0,01
A mm
48
B mm
65
C mm
55
E mm
18
F mm
15,5
CB01010WP
Range mm
0 ÷ 10
Resolution mm
0,01
A mm
435
B mm
69,5
C mm
58
E mm
16,5
F mm
16,5
